After all Una’s have booted up (Powerline & Wi-Fi LED’s will be amber), pair the Una’s to create
the Powerline backhaul network using the pairing button. Pairing is to be performed one Una at a
time. Pair one Una and then pair the second, third etc. Start the pairing process with the Una that
is connected to the Internet router. By initiating the pairing process from the Una that is connected
to the Internet router, it then becomes the domain master and CAP.
Pairing Una’s
1. Press and hold the pairing button for 3 to 5 seconds on the Una that is connected to the
Internet router first until the Powerline LED starts to blink – release the pairing button.
2. Press and hold the pairing button for 3 to 5 seconds on the second Una until the Powerline
LED starts to blink – release the pairing button.
3. The blinking Powerline LED indicates that the pairing process has started. The pairing
process takes approximately 40 to 60 seconds to complete.
4. The pairing process is complete when the Powerline LED on the Una connected to the
Internet router stops rapidly blinking and is solid green and the second Una Powerline
LED is solid green.
NOTE: If the Powerline LED is off or amber, perform a reset to factory default on the Una that is
exhibiting the issue and repeat the pairing process.
