Technical Specifications
Main Chipset Qualcomm Cortex quad-core A7 processor with WLAN radios &
Maxlinear wave two G.hn Powerline SOC
Computer Interface
IEEE802.3 /u/ab 10/100/1000 BASE-T
Dual band, dual concurrent wireless radios
Operating Standards
IEEE 802.11k, 802.11v
IEEE 1905.1
IEEE 802.3ab
ITU-T G.hn G.9963
PHY Data rate 2 x 2 AC1200 Wi-Fi
1.5 Gbps from 2 to 80MHz Powerline
Network Interface
1 x RJ-45 (10/100/1000Base-T Ethernet)
1 x NEMA 5 120VAC 1.5 Gbps Powerline interface
Quality of Service 8 levels of Powerline packet-prioritized QoS
Security Wi-Fi: 64/128 bit WPA2 - PSK, AES. G.hn 128-bit AES Link
Encryption with Key Management
Modulation Schemes
TDMA channel access scheme
OFDM symbol modulation on line synchronization
1024/256/64/16/8 - QAM, QPSK, BPSK, ROBO carrier modulation
Operational Range Wi-Fi: 2.4 GHz & 5 GHz Concurrent, Distance: 1,500sq ft (457m)
Powerline: 1.5 GB PHY, 2 to 80 MHz, Distance: 1,000ft (305m)
Cabling 1000Base-T; UTP Cable
Operating Temperature
-5° C to +45° C ambient temperature
Storage Temperature
-20° C to +85° C ambient temperature
Humidity 5% to 95% maximum (non-condensing)
Power Input 100 ~ 240V @ 50/60Hz Internal
Power consumption 5.81W @ 80dB_Bidirectional
Dimensions H 4.7” x W 2.5” x D 1.7” (120mm x 65mm x 43mm)
Regulatory Compliance
FCC Part 15 Class B
CE IEC 60950-1
