Section 904
Accelerometer TL-3424_EXT
904 - 6 Page Date: 19. February 2014
Pilot´s Operating Handbook US
EXTRA 330LX
SYMBOLS
The following symbols are used in the TL-3424_EXT display.
Display Symbol Meaning
recording to memory
ll Recording paused
ACC Acceleration values indicated
up/down arrows storing expected, release buttons when setting arrows vanish
CONTROLLING THE INSTRUMENT VIA NAV-MENU
There are black labels on the display. Each is affiliated to the left and the right button. The
left label is for the Left button. The right label is for the Right button. Before pressing a
button, read the information on the label. Its functions are different in every menu.
To store a value into the memory, press both buttons simultaneously. Release buttons when
the setting arrows vanish.
SETTING THE DISPLAY BRIGHTNESS
Press and hold both buttons while switching on the TL 3424 to enter the setup.
Follow the menu navigation.
To Next Page
