Extra 330lx - Load Factor; Load Factor Limitations

Page Date: 19. February 2014 2 - 7
Section 2
Limitations
Pilot´s Operating Handbook US
EXTRA 330LX
Maneuvers Recommended entry speeds IAS Symbol Remarks
min knots (km/h) max knots (km/h)
Segment:
horizontal Line V
S
V
NE
45°climbing 80 (148) V
NE
90° up V
A
V
NE
45° diving V
S
V
NE
reduce throttle
90° diving V
S
V
NE
reduce throttle
1/4 Loop climb. 100 (185) 190 (352)
Loop 100 (185) 190 (352)
Stall turn 100 (185) 190 (352)
Aileron roll 80 (148) 185 (343) full deflection
Snap roll 80 (148) 140 (259)
"tail slide" 100 (185) 190 (352)
Spin V
S
Inverted spin V
S
Knife edge >150 (278) < 10 s
Inverted Flight >V
S
190 (352) < 4 min
2.9 LOAD FACTOR
2.9.1 RESERVED
2.9.2 ACROBATIC FLIGHT
Category I MTOW 820 kg (1808 lbs) + 10 g / - 10 g for 1 seat occupied
Category II MTOW 870 kg (1918 lbs) + 8 g / - 8 g for 2 seat occupied
Category III MTOW 950 kg (2095 lbs) + 6 g / - 6 g for 2 seat occupied
