Extra 330lx - Take-Off Performance; Take-Off Performance Data

5 - 8 Page Date: 19. February 2014
Section 5
Performance
Pilot´s Operating Handbook US
EXTRA 330LX
5.5 TAKE-OFF PERFORMANCE
Power : T/O Power
Runway: Concrete
N O T E
For every 5 kts (9 km/h) headwind, the T/O distance can be decreased by 4%. For
every 3 kts (6 km/h) tailwind [up to 10 kts (19 km/h)], the T/O distance is increased by
10%. On a solid, dry and plain grass runway, the T/O is increased by 15%.
OAT 0°C (32°F) 15°C (59°F) 30°C (86°F)
T/O Rotate PA T/O T/O T/O T/O T/O T/O
weight Speed Roll over Roll over Roll over
15 m (50 ft) 15 m (50 ft) 15 m (50 ft)
kg KIAS ft (m) m (ft) m (ft) m (ft) m (ft) m (ft) m (ft)
(lbs) (km/h)
950 68 SL 96 (315) 207 (679) 115 (377) 248 (813) 133 (436) 285 (935)
(2095) (126) 2000 (610) 115 (377) 248 (814) 138 (453) 298 (978) 160 (525) 342 (1122)
4000 (1219) 138 (453) 298 (978) 166 (545) 357 (1171) 192 (630) 410 (1345)
6000 (1829) 166 (545) 358 (1175) 199 (653) 429 (1407) 230 (755) 492 (1614)
870 65 SL 78 (256) 167 (548) 93 (305) 200 (656) 107 (351) 230 (755)
(1918) (120) 2000 (610) 94 (308) 200 (656) 112 (367) 240 (787) 128 (420) 276 (906)
4000 (1219) 112 (367) 241 (791) 134 (440) 288 (945) 154 (505) 331 (1086)
6000 (1829) 135 (443) 289 (948) 161 (528) 346 (1135) 185 (607) 397 (1302)
820 63 SL 67 (220) 114 (374) 79 (259) 170 (558) 93 (305) 200 (656)
(1808) (117) 2000 (610) 80 (262) 173 (568) 95 (312) 204 (669) 112 (367) 240 (787)
4000 (1219) 97 (318) 207 (679) 114 (374) 248 (814) 134 (440) 288 (945)
6000 (1829) 116 (381) 249 (817) 137 (449) 294 (965) 161 (528) 347 (1138)
