Extra 330lx - Equipment List

6 - 10 Page Date: 19. February 2014
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook US
EXTRA 330LX
EXTRA 330LX S/N:
QTY ITEM MANUFACT. MODEL NO PART OR P/N WEIGHT ARM R* INST
(kg) (m) A
O
*) R = required, A = alternative, O = optional
6.6 EQUIPMENT LIST
Mooring (10)
2 Wing Tie Down Rings Extra 8C801.002 0.05 1.07 O
1 Canopy Lock Extra 83401.001-LK 0.25 1.90 O
Venting and Heating (21)
1 Heater Extra EA-8D606 Option 300/LT 3.70 0.20 O
KBS01
Electrics (24)
1 Battery Concorde RG-25 XC 03617 10.40 0.23 R
1 Battery Lightweight Concorde RG-12LSA 03617 5.90 0.23 A
1 Alternator 60 Amps Plane Power AL12-EI60/B 33552 3.00 -0.86 R
1 Alternator 65 Amps Prestolite 66021637 33558 4.00 -0.86 A
1 Alternator 55 Amps Bosch 0 120 489 917 33508 4.60 -0.86 A
1 Shunt (100A. 100mV) Electronics International S-50 FA3008 0.09 0.25 R
1 Volt/Ammeter Electronics International VA-1A-50 FA3007-PG 0.22 1.62 R
1 External Power Socket Cole Hersee 11041-06 31731 1.46 1.07 O
(Piper Type)
1 Batt. Charger Plug 12V Extra EA-93102.18 02636 0.02 0.17 O
1 12VDC Power Outlet Sutars 1218 31494 0.03 1.62 O
Socket
Cockpit (25)
1 Safety Belt Assy Hooker (1011230 [3x] & FK0002 or FK0019 3.30 2.12 R
Rear Seat 1113012-1 [1x],
(seat belts w. ratchet, 1H5630-3 [2x]
shoulder harness, 1CS924-D [1x])
crotch strap)
1 Safety Belt Assy Hooker 1011230 [4x] 2.90 1.03 R
Front Seat 1H3030-3 [2x]
(seat belts, 1CS924-D [1x]
shoulder harness,
crotch strap)
1 Safety Belt Assy Hooker (1011230 [3x] & FK0004 or FK0020 3.30 1.03 A
Front Seat 1113012-1 [1x],
(seat belts w. ratchet, 1H3030-3 [2x]
shoulder harness, 1CS924-D [1x])
crotch strap)
Emergency Equipment
1 First Aid Pack Hartmann 7394280 33423 0.39 2.70 R
Flight Controls (27)
1 Elevator Trim System Ray Allen EA-4D401.0 31668 0.40 4.24 R
Electric
1 Mechanically Extra EA-46304 4.92 1.22 R
Adjustable Pedal Sys.
