Page Date: 19. February 2014 6 - 11
Section 6
Weight and Balance and Equipment List
PilotĀ“s Operating Handbook US
EXTRA 330LX
1 Electrically Extra EA-86612 7.28 1.10 A
Adjustable Pedals Sys.
Fuel System (28)
1 Elec. Fuel Pump Weldon Tool B8120-M 1.10 -0.04 R
1 Elec. Fuel Pump Andair PX580-TC-XT 0.47 -0.04 A
1 Fuel Selector Allen 6 S 122 390144 0.19 0.73 R
+ Fuel Lines in Fuselage Parker/Statoflex PTFE Type 124 33315 1.65 0.70 R
1/2 Fuel Cont. Probe Wing VDO 226 801 015 001 FM4006 0.12 0.89 R
1 Fuel Cont. Probe VDO 224 011 020 372 01920 0.20 0.44 R
Fuselage Tank
Landing gear (32)
2 Main Wheel Tires Goodyear 505C61-B 02323 3.90 0.33 R
5.00-5 / 6PR
2 Tube Goodyear 302-013-400 FF0016 R
2 Main Wheel Tires McCreary 06-08200 A
5.00-5 / 6PR
2 Tube McCreary 06-08300 A
2 Wheel assembly Cleveland 199-197 02497 6.40 0.33 R
2 Master Brake Matco MC-4E FB0001 0.55 0.15 R
Cylinders front
2 Master Brake Matco MC-4E FB0001 0.55 1.11 R
Cylinders rear
1 Tail Wheel 6" Assy Special Products 32477-VB 1.28 5.23 R
(Soft) Aviation Inc.
1 Tail Wheel 5" Steerable Extra EA-53201.7 53201.007-VB 0.90 5.23 A
L/R Wheel fairing (CRP) Extra EA-53102.301 0.33 2.50 R
1 Brake Fluid Reservoir ACS A-315 02889 0.20 0.04 R
Lights (33)
1 Strobe / Nav Light (RH) Whelen 01-0790340-00 32989 0.30 1.35 R
(14V green)
1 Strobe / Nav Light (LH) Whelen 01-0790340-02 32990 0.30 1.35 R
(14V red)
2 Strobe Power Supply Whelen A490T 01215 0.54 1.35 R
1 Landing Light LED Whelen 01-71125-12 33588 0.16 -0.57 O
Navigation / Flight Instruments / Avionics (34)
1 Accelerometer 3-1/8" Kollsman/Pioneer/ AN 5745 FI3001 0.40 1.60 R
Bendix/Jaeger/Century
1 Accelerometer 2-1/4" Kollsman/Pioneer/ AN 5745 01206 0.30 1.60 A
Bendix/Jaeger/Century
1 Magnetic Compass SIRS Navigation Ltd PG2A 33085 0.13 1.62 R
1 Magnetic Compass Airpath C 2300 00189 0.25 1.62 A
1 Airspeed Indicator United Instr. UI8030 B.882 32811 0.32 0.65 O
front (kts)
1 Airspeed Indicator United Instr. UI8030 B.896 33630 0.32 0.65 A
front (kts/km/h)
QTY ITEM MANUFACT. MODEL NO PART OR P/N WEIGHT ARM R* INST
(kg) (m) A
O
