Extra 330lx - Page 80

6 - 12 Page Date: 19. February 2014
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook US
EXTRA 330LX
1 Airspeed Ind. front (kts) Mikrotechna Praha LUN 1106.K2B4/SC 34155 0.50 0.65 A
reserved
1 Airspeed Indicator United Instr. UI8030 B.882 32811 0.32 1.61 R
rear (kts)
1 Airspeed Indicator United Instr. UI8030 B.896 33630 0.32 1.61 A
rear (kts/km/h)
1 Airspeed Ind. rear (kts) Mikrotechna Praha LUN 1106.K2B4/SC 34155 0.50 1.61 A
reserved
1 Alternate Static Valve Extra Assy 300/L Option 0.15 1.60 O
StatLei
1 Altimeter front (ft) United Instr. UI5934PD-3 30416 0.39 0.66 O
A.134
reserved
1 Altimeter front (ft) Mikrotechna Praha LUN 1128.10B6 34159 0.59 0.65 A
reserved
1 Altimeter rear (ft) United Instr. UI5934PD-3 30416 0.39 1.62 R
A.134
reserved
1 Altimeter rear (ft) Mikrotechna Praha LUN 1128.10B6 34159 0.59 1.61 A
reserved
1 Vertical Speed United Instr. UI7030 C.27 01485 0.54 1.62 O
Indicator (fpm)
reserved
1 Vertical Speed Ind. (fpm) Mikrotechna Praha LUN 1144.B0B1 34161 0.40 1.61 A
reserved
1 Attitude Gyro RC Allen RCA2600-2 (0° tilt) 33027 0.24 1.63 O
(electronic. 2 1/4")
1 Attitude Gyro RC Allen RCA2600-2 (0° tilt) 33881 0.13 1.61 A
(electronic. 2 1/4") 102-0202-01
1 Attitude Gyro RC Allen RCA2600-3 (0° tilt) 33217 0.45 1.63 A
(electronic. 3 1/8")
1 Attitude Gyro RC Allen RCA2600-3 (0° tilt) 33882 0.19 1.61 A
(electronic. 3 1/8") 102-0203-01
1 Slip Indicator RC Allen 444-0010-01 33529 0.03 1.63 A
(on RCA 2600)
1 Stall Sensor Extra EA-73106.0 7D106.001-VB 0.07 0.45
1 Stall Warn Horn EMAG EM-S 110P 01600 0.13 1.60 O
1/1 Slip/Skid Indicator Rieker 1040 FI0009 0.05 1.60 O
Optional Primary Flight Display (ASPEN)
1 Electr. Flight Display Aspen 910-00001-001 in 33846, 33291, 1.32 1.55 O
(EFD1000) 34020 & 34021
1 Configuration Module Aspen 920-00004-001 in 33846 & 34020 0.04 1.50 O
(Pilot)
1 Configuration Module Aspen 920-00004-002 in 33291 & 34021 0.04 1.50 O
(Pro)
QTY ITEM MANUFACT. MODEL NO PART OR P/N WEIGHT ARM R* INST
(kg) (m) A
O
Reserved
