Section 906
Digital RPM Indicator
Page Date: 19. February 2014 906 - 3
PilotĀ“s Operating Handbook US
EXTRA 330LX
906 DIGITAL RPM INDICATOR
906.1 GENERAL
The EXTRA 330LX is as standard equipped with an "P-1000" Digital rpm indicator. The
following model is used:
P100-230-635-00 (max. 2600 rpm)
.
906.2 LIMITATIONS
The operation limitations are not affected by the installation of the "P-1000" Digital RPM
indicator.
The face of the indicator is placarded with the unchanged engine RPM operating range.
Additionally the operating RPM ranges are indicated by a large green, yellow, and a red LED.
These LEDs are located on the upper right corner of the indicator face.
Model P100-230-635-00 (max. 2600RPM):
906.3 EMERGENCY PROCEDURES
Not affected.
906.4 NORMAL PROCEDURES
Not affected
906.5 PERFORMANCE
Not affected.
Green -------- Yellow -------- Red --------
2400 2600 3500
700 2400 2600
