Extra 330lx - Page 26

2 - 10 Page Date: 19. February 2014
Section 2
Limitations
Pilot´s Operating Handbook US
EXTRA 330LX
(in both cockpits next to the fuel selector)
(On the rear instrument panel beneath wing tank fuel capacity indicator)
(On the rear instrument panel beneath center tank fuel capacity indicator)
(On the rear instrument panel beneath the acro & center tanks fuel capacity indicators)
(In both cockpits)
(In both cockpits)
(On the right side of both instrument panels)
NO SMOKING
CENTER TANK INDICATION
SHOWS "ZERO" IN LEVEL FLIGHT
BELOW 9 L (2.4 US GAL).
UNUSABLE FUEL 2 L (0.5 US GAL)
THE REMAINING FUEL IN LEVEL
FLIGHT CANNOT BE USED SAFELY
WHEN INDICATOR READS "ZERO"!
ACROBATIC:
±10 G, 1 Pilot, MTOW: 820 kg (1808 lbs)
± 8 G, 2 Persons on board, MTOW: 870 kg (1918 lbs)
± 6 G, 2 Persons on board, MTOW: 950 kg (2095 lbs)
USE OF HEADSET IS REQUIRED
USE OF PARACHUTE IS RECOMMENDED
FUEL SELECTOR VALVE
WING TANKS
usable 120 L (31.7 US GAL)
OFF
CENTER
(ACRO)
TANK
usable 67 L
(17.7 US GAL)
WING TANK
MUST BE EMPTY FOR ACROBATICS.
USABLE FUEL 120L (31.7 US GAL).
