Extra 330lx - Page 84

6 - 16 Page Date: 19. February 2014
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook US
EXTRA 330LX
QTY ITEM MANUFACT. MODEL NO PART OR P/N WEIGHT ARM R* INST
(kg) (m) A
O
Optional add on to convent eng. Gauges
1 Fuel Scan Sys. JPI FS-450 30611-PG 0.18 0.98 O
1 Fuel Flow Transducer Flowscan 201-B or FXT-201 0.09 -0.02 O
Shadin 680501 or 680600 FI4015 0.09 -0.02 A
1 Engine Monitor Sys. JPI EDM700/800 31530-PG 1.39 0.50 O
6 EGT Probe JPI M-111 0.35 -0.57 O
6 CHT Probe JPI M-113 (S-Plug Gask.) 0.26 -0.56 O
1 OAT Probe JPI 400510 0.05 O
1 Oil Temp Probe JPI 400500-L 0.05 -0.22 O
1 Manifold Press. Probe JPI 604010 0.05 1.55 O
1 RPM Probe JPI 420809 0.05 -0.11 O
1 Fuel Flow Transducer Flowscan 201-B or FXT-201 0.09 -0.02 O
Shadin 680501 or 680600 FI4015 0.09 -0.02 A
Exhaust (78)
1 Exhaust System "6 in 1" Gomolzig EA300-606000 33891 8.48 -0.39 R
(incl. silencer) with
1 2" inlet/outlet cooling Gomolzig EA300-606009 32153
shroud
1 Exhaust System "6 in 1" Gomolzig EA300-606000 33891 8.48 -0.39 A
(incl. silencer) with
1 3" inlet/outlet cooling Gomolzig EA300-606024 03248
shroud for heating system
Oil System (79)
1 Single Oilcooler rear Aero Classics 8000353 31417 1.65 -0.22 R
1 Low Temperature Extra EA-83301 300 Option 0.20 -0.01 A
Breather Line Kit cold weather kit
Starting (80)
1 Starter Flyweight Sky-Tec 149-12LS 32865 3.74 -0.85 R
1 Starter High-Torque Sky-Tec 149-12NL 30552 4.26 -0.85 A
inline
Ground Equipment
1 Batt. Charger Cable Extra Assy 03543 O
1 External Power Cable Extra Assy 31730 O
1 Smoke Filling Hose Extra Assy 86100.000-24 O
