FRONT PELLET FEEDING KIT OPTIONAL
The optional pellet feeding kit allows pellets to be fed into
the feed-box from the front without having to extract the
insert (operation that requires machine switch-o).
Further information on the accessories is available on the
website, in the category "accessories".
AIR CIRCULATION PIPES
Create air recirculation inside the structure that covers the insert for correct operation. This prevents the appliance from over-
heating.
To guarantee this, just make one or more openings in the lower and upper parts of the covering.
The following measurements must be respected:
LOWER PART COLD AIR INLET WITH TOTAL MINIMUM SURFACE 550 CM².
UPPER PART HOT AIR OUTLET WITH TOTAL MINIMUM SURFACE 550 CM².
THIS VENTILATION SYSTEM IS TOTALLY INDEPENDENT FROM THE AIR INTAKE FOR COMBUSTION!!
20
