*2ND TIME SLOT SWITCHON
At this point, the second time slot must be programmed.
The sequence to be followed is the same and is repeated as per the 1ST TIME SLOT SWITCHON.
On this occasion simply enter the time, for example start at 15:00 and Stop at 22:00 and to activate the days Saturday and
Sunday by setting them at "ON".
J
WHEN THE WEEKLY PROGRAMMER IS ACTIVE, A BOX OF THE RELATIVE ICON WILL APPEAR ON THE
CONTROL BOARD.
PROGRAMMING EXAMPLE
Let's suppose that the weekly Programmer function is to be used and 4 time slots are to be used in the following way:
- 1st time slot: from 08:00 to 12:00 every day of the week, with room temperature at 19°C, excluding Saturday and
Sunday
- 2nd time slot: from 15:00 to 22:00 only on Saturday and Sunday, with room temperature at 21°C
CONTROLS PROCEDURE:
Press key 5 and SET CLOCK will appear.
Press key 3 until enable chrono
appears
Enable the chrono
Enable slot 1 and 2.
Press key 1 to exit
SET
CLOCK
ENABLE
CHRONO
1ST TIME SLOT SWITCHOFF
Use keys 2 - 3 to enter the time “12:00”
which corresponds to the switch-o
time of the 1st time slot.
To conrm and continue programming,
press button 5. Press button 4 to go
back to the previous parameter.
STOP PRG1
12:00
* Where “ENABLE CHRONO” is not
present in the menu, enabling is done
directly in SET CHRONO.
CONTROLS PROCEDURE:
Press key 3 and SET CHRONO will
appear.
CHRONO
SETTING
ENABLING THE 1ST TIME SLOT DAYS
To enable/ disable the days, use keys 2
and 3 ; key 4 and 5 to scroll the various
days, the day of the week will appear,
followed by OFF
select from Monday to Friday on ON,
excluding Saturday and Sunday (OFF)
MONDAY..PRG1
ONOFF
Press key 5 to conrm and continue
programming.
START PRG1 OFF will appear.
START PRG1
OFF
1ST TIME SLOT TEMPERATURE
SETTING
Press key 5 to conrm and continue
programming.
Using keys 2 - 3 select the desired
temperature.
(Low -07 - 40°C Hot)
To conrm and proceed press key 5.
SET PRG1
19°C
1ST TIME SLOT SWITCHON
Use keys 2 - 3 to enter the time “08:00”
which corresponds to the switch-on
time of the 1st time slot.
To conrm and continue programming,
press button 5. Press button 4 to go
back to the previous parameter.
START PRG1
08:00
2ND TIME SLOT SWITCHON*
At this point, the second time slot must
be programmed.
The sequence to be followed is the
same and is repeated as per the 1ST
TIME SLOT SWITCHON.
START PRG2
OFF
