ENGLISH
The 2 side frames are xed to the upper
frame by means of 2 screws each side.
The remaining holes on the side frames
allow to x the entire frame to the sides
of the machine by means of self-drilling
screws.
Open the tank lid and load the pellets using a scoop.
MOUNTING THE FRAMES
 Front frame
 Side frames
N.B. Any wooden beams located above the insert must be
protected with non-inammable material.
Frame assembly is important as it allows correct recirculation
of the air and consequently optimal product operation.
PELLETS AND FEEDING
The pellet used must comply with the features described by
Standards:
 EN PLUS  UNI EN 14961  2 UNI EN ISO 172252 class
A1  A2
The Manufacturer recommends using pellets with a diameter of
6mm with its products.
To guarantee combustion without problems, the pellets must be kept in a dry place.
We recommend using pellets with a diameter of 6 mm with our products.
See the images for feeding pellets.
Open the tank lid and load the pellets using a scoop.
In the event of the inserts, only load when the machine is o and cold, by extracting it from the compartment.
In the event of installation with feeding kit (optional) the machine must not be extracted.
THE INSERT MUST OVERLAP THE MARBLE
COVERING SURFACE BY AT LEAST 1 CM.
MAINTENANCE OPERATIONS MUST BE PERFORMED
WHEN THE INSERT IS OFF, WITH THE PLUG
DISCONNECTED FROM THE SOCKET.
THE USE OF POOR QUALITY PELLETS OR ANY OTHER MATERIAL DAMAGES THE FUNCTIONS OF YOUR STOVE AND
CAN
VOID
THE
WARR
ANT
Y AND
THE ANNEXED RESPONSIBILIT
Y OF
THE MANUFACTURER.
23
