Table 12: Extreme Networks 100Gb Direct-Attach Cables (continued)
Cable Type Part Number Length
QSFP28-4xSFP28 (4x25Gb) Direct attach passive
copper breakout
10421 1 meter
10423 3 meters
10424 5 meters
QSFP28-4xSFP28 (4x25Gb) Active optical breakout
cable
10444 20 meters
Table 13: Extreme Networks 40Gb Direct-Attach Cables
Cable Type Part Number Length
QSFP+ to QSFP+ Direct attach cable AA1404037-E6 0.5 meter
AA1404029-E6 1 meter
AA1404030-E6 2 meters
AA1404031-E6 3 meters
AA1404032-E6 5 meters
QSFP+ to QSFP+ Active optical cable AA1404028-E6 10 meters active
optical
QSFP+ to 4xSFP+ Breakout cable AA1404033-E6 1 meter
AA1404035-E6 3 meters
AA1404036-E6 5 meters
AA1404041-E6 10 meters active
optical
Using RJ45 Connector Jackets
Use RJ45 cable with connector jackets that are flush with the connector or that have connectors with a
no-snag feature.
Using cable with jackets that are wider than the connectors can cause:
• Connectors that are not properly aligned with the port.
• Crowded cable installation, which can cause connectors to pop out of the port.
Figure 32 shows examples of recommended and non-recommended connector jacket types.
Using RJ45 Connector Jackets
Site Preparation
44 ExtremeSwitching 5420 Series Hardware Installation Guide
