8 CrossPoint / MAV Matrix Switchers • Installation
Front Panel Configuration Port
(Matrix Sizes up to 1616, MAV Plus 32 A, and
MAV Plus 248 A)
AUDIO
VIDEO
I/O
CONTROL
ENTERPRESET
VIEW
ESC
CONFIG
ULTRA-WIDEBAND MATRIX SWITCHER WITH ADSP
™
CROSSPOINT ULTRA SERIES
1
Figure 8. Front Panel Configuration Port
a
Configuration port — If desired, connect a control system or
computer to the front panel Configuration (RS-232) port. Use
an optional Extron 9-pin D to 2.5 mm mini jack TRS RS-232
cable.
