Extron electronics TouchLink TLP Pro 1020 Series User Manual

C
Menu button (see figure 5)— activates the setup menu (see the following page) and
Calibration screen (see page19).
D
Reset button (see figure 5)— initiates one of three reset modes for the unit (see Reset
Modes on page30).
E
Reset LED (see figure 5)— indicates power status and reset status of the device (see
Reset Modes on page 30).
F
VESA mounting holes (4) (see figure 5)— for use with the Extron LPVM-1 (see VESA
Mounting on page 28).
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 13

Extron electronics TouchLink TLP Pro 1020 Series Specifications

General

Brand	Extron electronics
Model	TouchLink TLP Pro 1020 Series
Category	Touch Panel
Language	English
