Reference
Material
This section describes:
z Reset Modes
z Licensed Third-Party Software Used in the Touchpanels
Reset Modes
The TLP Pro 720 Series and TLP Pro 1020 Series touchpanels have three reset modes that are
initiated by pressing the Reset button:
z Use Factory Firmware
z Reset All IP Settings
z Reset to Factory Defaults
The Reset button on the TLPPro720M or TLPPro1020M, is found on the front panel after
removing the bezel see figure 4 on page 7). The Reset button for the TLP Pro 720T or
TLPPro1020T is found on the rear panel (see figure 5 on page 8).
Use Factory Firmware
Activation
To start the Use Factory Firmware reset mode and replace firmware:
1. On the touchpanel, hold down the recessed Reset button while applying power to the unit.
2. When power is restored, the Power LED lights. Hold the Reset button for a further two
seconds before releasing it. The touchpanel enters factory firmware mode, and the LED
flashes quickly.
3. Upload new firmware to the unit as desired (see Updating the Firmware on page 22).
NOTE: After a User Factory Firmware reset is performed, update the touchpanel
firmware to the latest version. Do not operate the touchpanel firmware version
that results from the reset. This mode temporarily resets the unit to factory default
firmware until the user updates the firmware or power is recycled. If you want
to use the factory default firmware, you must upload that version again (see
Updating the Firmware on page 22)
.
Result
The unit continues to run factory-installed firmware until you update the firmware or power
is cycled to the unit, which then reboots with the last loaded version of the firmware. The
touchpanel reverts to the factory default firmware. Event scripting does not start if the unit is
powered on in this mode. All user files and settings such as drivers, adjustments, and IP settings
are maintained.
NOTE: To return the unit to the firmware version that was running prior to the reset,
cycle power to the unit.
TLP Pro 720 Series and TLP Pro 1020 Series • Reference Material 30
