Using the Software
GUI Designer
Use the GUI Designer software to design the screen layout for the touchpanel. See the
GUIDesigner Help file for step-by-step instructions and more detailed information.
Global Configurator
Use the Global Configurator software to set up and configure the control processor and the
touchpanel. See the Global Configurator Plus and Global Configurator Professional Help File for
step-by-step instructions and more detailed information. The Global Configurator Plus and Global
Configurator Professional Help File also includes an introduction to the software and sections on
how to start and configure a project.
TLP Pro 720 Series and TLP Pro 1020 Series Web Pages
To access the touchpanel default web pages, enter the IP address of the unit into the web
browser of a PC connected to the same subnet. There is a single, read-only page that provides
general and network information about
A dialog opens asking for your user name and password. By default, the user name is
admin
and the password is extron (both user name and password are all lower case).
The single page provides general and network information about the unit. It also allows you to
upgrade the unit firmware.
Use the Setup Menu (see page 14) or the Toolbelt feature of Global Configurator to configure
the touchpanel network settings.
Figure 17 shows the TLP Pro 1020T web page. The web page for the other touchpanels is
similar.
Extron Electronics
®
General Status
Model Name: TLP Pro 1020 T
Description:TouchLink Pro Tabletop
Part Number: 60-1392-01
Firmware Version: 1.00
Date: Monday, May 27, 2013
Time: 7:58 PM
POE:On
Up Time: 0 day(s) 1 hour(s) 23 minute(s)
License Information
IP
DHCP: Off
Host Name: TLP-Pro-1020T- 0B-37-38
IPv4 IP Address: 192-168-254-251
DNS (IP): 127.0.0.1
Gateway IP: 0.0.0.0
Subnet Mask: 255.255.255.0
Mac Address: 00-05-A6-XX-XX-XX
Project
No Project Configured
System Devices
Device Name Part Number Hostname/IP
Firmware Upgrades
Firmware:
Browse Upload
Figure 17. TLP Pro 1020T Web Page
TLP Pro 720 Series and TLP Pro 1020 Series • Configuration Software 21
