Calibration Screen
Touch crosshair to calibrate
800 x 480
Figure 16. Calibration Screen
1. Press and hold down the Menu button for at least 3 seconds.
For the TLP Pro 720T and TLP Pro 1020T, the Menu button is located on the rear panel (see
figure 5,
C
on page 8).
For the TLPPro720M and TLP Pro 1020M, the Menu button is located on the front panel
and the bezel must be removed first (see figure 4,
B
on page 7).
2. Release the button. The calibration screen opens to show cross-hairs.
3. Follow the on-screen instructions until all five sets of cross hairs have been calibrated (one in
each corner and a fifth in the center of the screen).
4. The touchpanel exits the calibration screen once the calibration process is completed.
5. Reattach the bezel.
TLP Pro 720 Series and TLP Pro 1020 Series • On-screen Menus 19
