EYE-LCD4600M/W-SN 19
) Press the SOURCE button to switch to the next input source. If Autoscan is enabled in the Input menu this
will trigger an input scan and the next active input is selected.
) You can reboot the display and read back saved settings at any time: press the sequence BLUE-RED-
YELLOW () to trigger a reset on the currently selected display. Press ADDRESS and then the
sequence BLUE-RED-YELLOW to reset every display in the wall
Note: Illustrated values may differ from your displayed OSD menu settings, depending on the firmware
version and connected signal sources
Do not forget to select “Save in the Main Menu if you want to save your changes for future startups.
3.2.1 Main Menu
Menu Item Description
Select Device Select the display to be addressed
Input Configuration settings concerning input Selection
Picture Setup General configuration settings concerning presentation of the output
Scaling Configuration settings concerning the size transformation of the input
Matrix Configuration Settings concerning splitting Output over several displays
Analogue RGB
Settings
Configuration applying only to Analogue RGB input
Network Configuration Configuration of the Network Board
Tools Miscenallenous utility settings
Status Run-time information about Dynamic Values
Power Scheduler Switch the display on an doff automatically at specified times
Info Hard- and Softwareinformation about the Display
Save Saving configuration settings permanently
Main Menu
Select Device
002
Input
Picture Setup
Scaling
Matrix
Analogue RGB Settings
Network Configuration
Tools
Status
Info
Power Scheduler
Save
