EYE-LCD4600M/W-SN 41
4.2 Firmware Update Scaler
) Power Off the display
) Connect the flasher cable (shown in picture) to the PC.
) Connect the flasher cable to port “AUX1” on the the display
) SET dipswitch No. 6 to On
) Start the “Flash Upgrader Software”
3 Choose Connection “Serial”
3 Choose Baud Rate “115000”
3 Select the appropriate COM-Port where the flasher cable is connected to
3 Press the “Flash”- Button
) Power On the Display to start the flash upgrade
) When the update is finished, reset DIP Switch No. 6 to off and restart the display
