Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
GENERAL SPECIFICATIONS
Owner’s Guide
19
GENERAL SPECIFICATIONS
MODEL: 2FIVE - 2 Passenger
TYPE: ELECTRIC LOW SPEED VEHICLE
MODEL YEAR: 2016
Part No:. 643508G01
Programmable AC Drive System: Factory programmable to application
z
Solid State variable frequency AC speed controller
z
235 Amp AC Controller
z
Driv e-by-w ire electronic throttle control
z
Full torque, reduced speed reverse
z
Dash mounted direction selector sw itch (Forward-N eutral-Rev erse)
z
Sealed Hall effect throttle sensor
z
Descent speed control and automatic hill hold
z
Full diagnostic capability (Hand held diagnostic unit)
z
Full-time regenerativ e braking
z
Dash mounted High/Low speed selector sw itch
Motor:
Battery Charger: On-board 48 VDC PowerWise™ H igh Frequency , 120/230 VAC 50/60 Hz w ith 30 amp DC -DC C onv ertor. (U.L. & C .S.A. Certified)
Electrical System: 48 Volt DC, four, 12 v olt deep cy cle storage batteries (60 minute minimum, 150 amp-hour @ 20 hr. discharge rate)
Drive T rain: Direct motor shaft connected to transax le pinion shaft
T ransaxle: Differential w ith rev erse helical gears
Brakes: 4-w heel hy draulic disc brakes and Induction motor. Electro-magnetic parking brake is applied automatically
Body Protection: Front, Rear & Side energy transfer bumpers
48 Volt AC induction motor, solid copper windings. 4.4 hp (3.3 kW) C ontinuous, 15 hp (11.2 kW) peak. AC sy stem reads motor speed for
accurate speed control in all conditions. Regenerative braking for max imum economy
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
