Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
GENERAL SPECIFICATIONS
Owner’s Guide
21
MODEL: 2FIVE - 4 Passenger
TYPE: ELECTRI C LOW SPEED VEHICLE
MODEL YEAR: 2016
Part No:. 643509G01
Programmable AC Drive System: Factory programmable to application
z
Solid State variable frequency AC speed controller
z
235 Amp AC Controller
z
Driv e-by -wire electronic throttle control
z
Full torque, reduced speed rev erse
z
Dash mounted direction selector sw itch (Forw ard-N eutral-Rev erse)
z
Sealed H all effect throttle sensor
z
Descent speed control and automatic hill hold
z
Full diagnostic capability (Hand held diagnostic unit)
z
Full-time regenerative braking
z
Dash mounted High/Low speed selector switch
Motor:
Battery Charger: On-board 48 VDC Pow erWise™ High Frequency , 120/230 VAC 50/60 H z with 30 amp DC-DC C onv ertor. (U.L. & C.S.A. C ertified)
Electrical System: 48 Volt DC, four, 12 v olt deep cy cle storage batteries (60 minute minimum, 150 amp-hour @ 20 hr. discharge rate)
Drive Train: Direct motor shaft connected to transax le pinion shaft
T ransaxle: Differential w ith rev erse helical gears
Brakes: 4-w heel hy draulic disc brakes and Induction motor. Electro-magnetic parking brake is applied automatically
Body Protection: Front, Rear & Side energy transfer bumpers
CONFIGURATION HIGHLIGHTS
48 Volt AC induction motor, solid copper w indings. 4.4 hp (3.3 kW) C ontinuous, 15 hp (11.2 kW) peak. A C sy stem reads motor speed for
accurate speed control in all conditions. Regenerativ e braking for max imum economy
PRODUCT SPECIFICATION
