Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
INTRODUCTION
Owner’s Guide
29
INTRODUCTION
FEATURES
General Information
If the vehicle has accessories that were installed at the
factory, some accessories continue to operate with the
key switch in the OFF position.
ALL accessories that do NOT use the accessory
wiring harness MUST be connected to the DC to DC
converter to pull from the full 48-Volt battery pack.
A DC to DC converter is necessary for the accessories that
need voltage different from 48 volts to operate correctly.
Attach negative wire
from the accessory to (BL-)
battery terminal
Attach power wire
from the accessory
to (BL+) battery
terminal

Ezgo 2Five Specifications

General

Seating Capacity	4
Drive Train	Rear-wheel drive
Category	Golf Cars
Power Source	Electric
Lights	LED headlights, taillights, and brake lights
Motor	AC induction motor
Brakes	Hydraulic Disc
Suspension	Independent front suspension with leaf spring rear suspension
Batteries	Six 8V deep cycle
Frame	Welded Steel
Instrumentation	Digital display
Mirrors	Side Mirrors
Safety Features	Seat belts, horn, and reflectors
Charger	On-Board Charger
Ground Clearance	4.5 inches
Top Speed	25 mph
