Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
INTRODUCTION
Owner’s Guide
33
3. Speedometer
The digital speedometer is located on the instrument panel to the left of key switch and indicates vehicle
speed in miles per hour.
4. Odometer
The digital odometer is located directly below the speedometer and indicates total miles driven on the
vehicle. The odometer will also display warning or error codes to alert the driver to potential problems with
the vehicle.
5. Headlight Switch
The headlight ON/OFF switch is located on the dash panel to the left of the speedometer.
6. Turn Signal/Hazard Switch
The turn signal switch is on steering column and controls the operation of the right and left turn signal lights.
To activate the hazard lights, pull the hazard switch away from the steering column. To deactivate,
temporarily flip the turn signal switch in either direction.
7. Brake Pedal
This vehicle is equipped with 4 wheel hydraulic disc brakes; the brake master cylinder is located under the
seat on the driver-side of the vehicle.

Ezgo 2Five Specifications

General

Seating Capacity	4
Drive Train	Rear-wheel drive
Category	Golf Cars
Power Source	Electric
Lights	LED headlights, taillights, and brake lights
Motor	AC induction motor
Brakes	Hydraulic Disc
Suspension	Independent front suspension with leaf spring rear suspension
Batteries	Six 8V deep cycle
Frame	Welded Steel
Instrumentation	Digital display
Mirrors	Side Mirrors
Safety Features	Seat belts, horn, and reflectors
Charger	On-Board Charger
Ground Clearance	4.5 inches
Top Speed	25 mph
