Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
INTRODUCTION
Owner’s Guide
35
11. Run/Tow Switch
The Run/Tow switch is used when the vehicle has become stalled
or inoperative. The switch is located below the seat on the pas-
senger side of the vehicle.
Chock tires before placing the vehicle in neutral and moving Run/Tow switch to TOW
position. Vehicle could roll and cause serious injury or death.
Before attempting to move the vehicle, turn the key switch to N and move the Run/Tow switch to
the TOW position. Failure to do so will damage the controller or motor.
The Run/Tow switch should always be returned to the RUN position after moving a stalled vehicle. If the
switch is left in the TOW position for an extended period of time, it will drain the batteries.
DO NOT alter or tamper with this unit. Unauthorized modifications can result in
SERIOUS INJURY or damage to the
vehicle and will void the warranty.
WAIT 30 seconds after reconnecting batteries BEFORE turning key switch to
‘REVERSE’, ‘FORWARD’ or ‘NEUTRAL’ positions.
TOWING - Always select ‘TOW’
position before towing
61259
4
To disable electrical system, turn key switch to ‘OFF
’ and remove battery wires.
ALWAYS turn key to ‘OFF
’ before disconnecting or reconnecting
b
a
ttery wires. ELECTRICAL ARC or BATTERY EXPLOSION can
occur if key is not in the ‘OFF’ position.
Splash Shield
Run/Tow Switch
