Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
OPERATING PROCEDURES
Owner’s Guide
57
If the AC is removed, the charger will turn off the receptacle LED and the charger will terminate charging.
• Charger input voltage 95 to 230 VAC power
• 9 Amp input current required
• Frequency 45-65 hertz
The charger will output 13A at 48V, and the DC to DC converter will output 30A at 12V.
To prevent a physical hazard that could result in an
electrical shock or electrocution, be sure that the
charger plug is not damaged and is inserted into a
grounded receptacle.
The optional charging (AC) cord is equipped with a polarized
connector that fits into a matching receptacle on the vehicle.
The receptacle is located on the driver side of the vehicle just
below the seat bottom.
