Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
MAINTENANCE
Always follow the cross-sequence pattern when you install the lug nuts to make sure the wheel is evenly
seated against the hub.
• With the valve stem to the outside of the wheel, install the wheel on the hub with lug nuts.
• Tighten the lug nuts (1) with your fingers in the cross-sequence pattern shown.
• Tighten the lug nuts to 63 to 77 ft. lbs. (85 to 105 Nm) torque in 20 ft. lbs. (27 Nm) increments.
• Continue to follow the cross-sequence pattern until the correct torque is reached.
Valve Stem Cap
Cross Sequence
Tire style may vary
1
