Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
MAINTENANCE
Owner’s Guide
85
To access the instructions remove three re-usable plastic rivets securing the controller
splash shield to the body and the controller. To remove the re-usable rivets, press the
center of the rivet with the vehicle key, when the center pin snaps into place the rivet can be
removed, repeat the process for each remaining rivet.
Turn the splash shield over to reveal the instructions for releasing the parking brake.
To reinstall the controller splash shield, position the splash shield by aligning the mounting
holes with the holes in the body, push the center pin of each rivet upward so that the top of
the pin is above the rivet head.
Place a rivet in each mounting hole of the controller splash shield and push down on the
center pin until the top of the pin is flush with the rivet head.

Ezgo 2Five Specifications

General

Seating Capacity	4
Drive Train	Rear-wheel drive
Category	Golf Cars
Power Source	Electric
Lights	LED headlights, taillights, and brake lights
Motor	AC induction motor
Brakes	Hydraulic Disc
Suspension	Independent front suspension with leaf spring rear suspension
Batteries	Six 8V deep cycle
Frame	Welded Steel
Instrumentation	Digital display
Mirrors	Side Mirrors
Safety Features	Seat belts, horn, and reflectors
Charger	On-Board Charger
Ground Clearance	4.5 inches
Top Speed	25 mph
