Option Description
Error Displays alerts that match the Error priority.
Warning Displays alerts that match the Warning priority.
Alert Displays alerts that match the Alert priority.
Info Displays alerts that match the Informational priority.
Options menu
Y
ou can use the Options menu to configure the LCD brightness and enable/disable the chassis locator
LED.
Option Description
Display Adjusts LCD backlight brightness.
Locator LED Controls the use of the chassis locator feature, which causes the F5
®
logo ball on the
chassis front panel to flash on and of
f. Select from these options:
• OFF (default)
• ON
Setup menu
Y
ou can use the Setup menu to configure the management interface, AOM management interface, and
serial port baud rate.
Option Description
Management Changes the management interface information. Select from these options:
•
Type indicates whether to use an IPv4 or IPv6 address.
• DHCP indicates whether DHCP is enabled or disabled (default).
• IP Address sets the management interface IP address and routing prefix. You
can use an IPv4 or IPv6 address.
• Gateway sets the default route for the management interface. This route is
necessary if you plan to manage the unit from a different subnetwork.
AOM Management Changes the AOM management interface information. Select from these options:
• Type indicates that the AOM management interface uses an IPv4 address.
• DHCP indicates whether DHCP is enabled or disabled (default).
• IP Address sets the management interface IP address and routing prefix. You
can use only an IPv4 address.
• Gateway sets the default route for the management interface. This route is
necessary if you plan to manage the unit from a different subnetwork.
Baud Rate Changes the baud rate of the management serial port. Select from these options:
• 9600
• 19200 (default)
• 38400
• 57600
• 115200
