FAAC S418 User Manual

2
Important Safety Information 3
Important Installation Information 3
General Safety Precautions 4
UL325 Gate Operator Classifications 5
Installing the Warning Signs 5
S418 OPERATOR
1. DESCRIPTION AND SPECIFICATIONS 6
1.1 Dimensions 6
1.2 Technical Specifications 7
1.3 Electrical Setup 7
2. INSTALLATION 7
2.1 Preliminary Checks 7
2.2 Installation Dimensions 7
2.3 Installing The Operator 8
2.4 Wiring The Operator 10
2.5 Mechanical Stops 10
3. MANUAL OPERATION 11
3.1 Restoring Normal Operation 12
4. MAINTENANCE AND REPAIRS 12
E024U CONTROL BOARD
1. Description and Characteristics 13
2. Inputs / Outputs Description 14
3. Safety Devices Connections 15
4. Programming 17
5. Led Diagnostics 20
6. Time Learning (Set-Up) 22
7. Obstacle Detection 23
8. Enclosure 23
9. Power Connection 24
10. Backup Battery 25
11. Firmware Upgrade 25
12. Function Logics 26
13. Accessories 29
SPARE PARTS
Spare Parts Diagram 32
TABLE OF CONTENTS

FAAC S418 Specifications

General

Power Supply	230V AC (+6% -10%) 50Hz
Motor Voltage	24V DC
Operating Temperature	-20°C to +55°C
Protection Class	IP54
Limit Switch Type	Magnetic
Control Voltage	24V DC
Frequency of Use	Intensive use
