Faber SILENCE - Preparing the Sense

UK/IRL
> > > > 19
5.2.3 Preparing the Sense
Pull the underside of the inner frame towards you. Push the blocking strips
up. Lift the inner frame and remove it.
5.2.4 Preparing the Widescreen and Whisper
1) Open the ashtray door by pushing on the right side for the
Silence/Feeling and on the left side for the Whisper. Remove the
frame by loosening the screws A behind the door (see fig. 5). Lift and
pull forward when you take it away
2) Remove the back panel by loosening the screws B (see fig. 6).
3) Remove the glass by removing the glass clamps C (see fig. 7) for
instance with a screwdriver. Careful when removing the glass! Wear
gloves! Before placing the glass back, be sure that there are no
fingerprints on the glass, it is not possible to remove them when they
are burnt in.
Fig. 3
Fig. 4
