Faber SILENCE - Preparing the Misty

UK/IRL
22 < < < <
Attention:
y If possible, first install the appliance before building up the false
chimney breast.
y If possible, install the the appliance, before installing the flue. If this
is not possible, a slidable piece of pipe should be used as connection.
y Leave a gap between the frame and wall, to ease the lifting and
removal of the frame. How this is done is described in paragraph 5.3.
5.2.6 Preparing the Misty
1) Remove the door frame. Lift and pull forward (see fig. 10).
2) Remove the outher frame by removing screws B (See fig. 11) and
taking away the frame.
Fig.10
Fig. 11
