7 Commisioning (functional checks)
7.1 Check pilot ignition
1. Push in and turn the control knob A from
anticlockwise to the
(small flame) setting. You will hear a tick meaning there is ignition.
Hold the knob in and wait for a few seconds while the air is purged.
2. Bring the knob back in the start position and turn the knob several
times to the
(large flame) position. Check that the pilot has lit.
3. Continue to hold in the control knob for a further ten seconds to
ensure that the pilot flame is stable.
4. Release the knob. The pilot should remain alight.
7.2 Functional burner check
1. Turn knob (B) to max. clockwise.
2. Turn the knob (A) more anticlockwise to the position
(large flame).
Now it is possible to light the main burner.
3. Turn knob B anticlockwise to max. The main burner should light. Check
for gas soundness at all joints with leak detection fluid!
4. Check the ignition of the main burner on low and high setting.
5. Turn knob B clockwise till
. The main burner is off.
6. Turn the knob A to
. The pilot should go out.
