6.3.1 Installation remote control
1. Connect the mains adapter to the receiver box. The adapter is set to
the correct voltage in the factory: 4.5 V.
2. Slide the receiver box into the holder.
3. Connect the wires to the gas valve (see fig. 22).
4. Check that there are batteries in the transmitter.
5. See "Replacing batteries", see chapter 10.4.4.
6. Set the on/off switch on the receiver to "on".
6.3.2 Setting the right transmission code
The receiver has to learn the code from the transmitter, which is already
done at the factory. However the code disappears if the receiver is
disconnected from the mains for a longer period.
1. Push the "mod" button on the receiver and hold it for 3 seconds.
2. The green control lamp will light up and stay on. Repeat this step if it
doesn't.
3. Push a button on the remote control. The control lamp on the receiver
should now go out.
4. Again push a button on the remote control. The lamp starts flashing
and will switch off eventually.
5. The receiver now recognizes the remote control. The remote control
now functions.
6. Check if you can hear a sound and the motor runs when you push a
button on the remote control.
fig. 22
fig. 22 fig. 21
