3) Take the box with the log set out of the combustion chamber.
4) Like in the previous models, place the right flue restrictor in the
combustion chamber (see fig. 13). To determine the right flue
restrictor, see paragraph 4.2 and 4.3.
Attention:
• If possible, first install the appliance before building up the false
chimney breast.
• If possible, install the the appliance, before installing the flue. If this
is not possible, a slidable piece of pipe should be used as connection.
5.3 Placing the appliance
Points of attention for placement:
• If possible, first locate the appliance before assembling the flue.
• If this is not possible then always use an extendible pipe before
connection onto the appliance.
1) Position the firebox in the fireplace opening. You can adjust the
height with the 4 adjustable feet.
2) Make the gas connection according to the instructions (also see gas
connection, chapter 5.1).
Fig.15
