Faber STRATUS NB Series - Choose Your Ducting Method

11
Non Ducted - Recirculation Options
Ducted Venting Options
Activated Charcoal Filter Accessory FILTER1 or FILTER1LL required (Purchased separately).
Register cover for air duct exit is shown for design not included.
Attention: When used in recirculation mode, To Reduce the Risk of Fire and Shock use only conversion
kit Model FILTER1 or FILTER1LL.
6 "
AB
Register cover for air
duct exit is suggested.
CHOOSE YOUR DUCTING METHOD
Two men required for installation Wear work gloves for safety
Caution: If an elbow is required, do it as far away from the hood's exhaust opening as possible
6 "
Roof
Exterior
Wall
