74
PARTES PRINCIPALES
REF. PIEZA CDAD.
A
Cuerpo de la campana, completo de: Controles, Luces, Filtros. 1
B
Soporte de montaje superior 2
C
Soporte de montaje inferior 2
D
Amortiguador ø 6" 1
E
Mando remoto 1
REF PIEZA CDAD.
F
Pernos Torx (1/4" x 9/16")
4
G
Tornillos Pozi (1/8" x 3/8")
8
D
E
A
B
C
F
G
