Faber STRATUS NB Series User Manual

8
MAIN PARTS
REF. PART QTY
A
Hood Body, complete with: Controls, Lights, Filters. 1
B
Upper Mounting Bracket 2
C
Lower Mounting Bracket 2
D
Damper ø 6" 1
E
Remote Control 1
REF PART QTY
F
Torx Bolts (1/4" x 9/16") 4
G
Pozi Screws (1/8" x 3/8") 8
D
E
A
B
C
F
G

Faber STRATUS NB Series Specifications

General

Brand	Faber
Model	STRATUS NB Series
Category	Ventilation Hood
Language	English
