17
1
2
Unfasten the 4 screws to dismount the Blower Box from the hood body and to save screws.
The Blower Box is not used for Remote Blower installation and can be discarded or saved for future
use if converted to Internal Blower.
Attach 10" FLANGE (2A) with 4 screws provided in
the hardware bag as shown.
OI\RXXVHWKHUHPRWHEORZHUNLW5%NLWRU5%NLWRU,Q/LQH%ORZHU2SWLRQSOHDVH
WKURZDZD\WKHÁDQJH$JLYHQZLWKWKHUHPRWHEORZHUNLWVKRZQRQSDJH
EXTERNAL BLOWER INSTALLATION
Separate the Box from the Range Hood
Attach optional FLANGE 10" (2A)
Torx Screwdriver
Torx Screwdriver
To Next Page
