Faber STRATUS NB Series User Manual

18
3
Connect the Hood body air outlet with the
Remote Blower air outlet.
4
Connect to Air Outlet
Connection to Box 2 (Remote Blower Wiring Box)
1. From inside the hood connect the cable
to the wiring box 2 as shown in the image
to the right.
2. From inside the hood, remove the cover from the
wiring box 2 by removing two screws.
3. Break the correct hole in the Wiring Box 2 for
passing the cables from the remote blower.
2
2
Box
1
2
