20
INSTALLATION OF RANGE HOOD BODY
X = A - 5 1/16"
$
PP
5 1/16"
6
As shown, you have to
accommodate for the
height of the hood body
into your space overhead.
After determining bracket
height use the 8 Screws
from Component Page 8 to
assemble brackets.
;
%[
5
Min. 7 5/16"
Max. 12 13/16"
Option A
6WHSVDEFLVDQRSWLRQIRUPRXQWLQJDQGKRRGZKHQDFFHVVLVDYDLODEOHIURPDERYHWKHFHLOLQJVRI¿W
(See page 20).
Option B
Steps 8a-8b-8c is an option for mounting the hood to the brackets when no access is available from above
DQGWKHVRI¿WLVDOUHDG\FRPSOHWHG6HHSDJH
Choose the correct method of bracket installation
Assemble the Range Hood Mounting Brackets
Ref. Size Picture
G
1/8" x 3/8"
G
To Next Page
