Apply Installation Compound to the inside of the seat tube.
Connect the Di2 cable to the battery. Insert seatpost into the
frame to the desired height.
Secure the seatpost by tightening the M8 grubscrew
to 6Nm
Lightly grease lower headset bearing and place on
fork crown race.
1-9
2-3
Assembly Manual 03
1-8
Lightly grease the upper headset bearing and then
install in upper headset cup.
Lightly grease the upper headset bearing and then install in
upper headset cup.
2-1 2-2
Note: Your Factor frame set requires a minimum of 90 mm
of seatpost insertion. The minimum insertion is clearly
marked on the seat post. Failure to achieve the minimum
insertion could cause damage to the seat post or frame
resulting in serious injury or death.
Fork, Stem and Headset Installation
