Fagor BCS3D - Page 10

10|52 - BCS3D EtherCAT Beta EtherCAT Servo 3 Drive series | Ref.2403
Installation Manual
FBM3J/FBM3G Feed Axis Motors
Medium inertia 0.20 kW feed axis motors
Medium inertia 0.40 kW feed axis motors
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 200 Vac
FBM3J-02ALA122 BCS3D-02AEA-FS02
FAGOR axis motor, 200 Vac, 0.20 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
waterproof plug type.
FBM3J-02ALA222 BCS3D-02AEA-FS02
FAGOR axis motor, 200 Vac, 0.20 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
waterproof plug type.
FBM3J-02ALA142 BCS3D-02AEA-FS02
FAGOR axis motor, 200 Vac, 0.20 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and waterproof plug type.
FBM3J-02ALA242 BCS3D-02AEA-FS02
FAGOR axis motor, 200 Vac, 0.20 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and waterproof plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3J-02ALA
 22 MPC-FBM3J-N9718- EEC-FBM3J-A1724-
03, 05, 08, 10, 15, 20
FBM3J-02ALA
 42 MPC-FBM3J-B9718-
EEC-FBM3J-A1724-
03, 05, 08, 10, 15, 20
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 200 Vac
FBM3J-04ALA122 BCS3D-04AEA-FS02
FAGOR axis motor, 200 Vac, 0.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
waterproof plug type.
FBM3J-04ALA222 BCS3D-04AEA-FS02
FAGOR axis motor, 200 Vac, 0.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
waterproof plug type.
FBM3J-04ALA142 BCS3D-04AEA-FS02
FAGOR axis motor, 200 Vac, 0.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and waterproof plug type.
FBM3J-04ALA242 BCS3D-04AEA-FS02
FAGOR axis motor, 200 Vac, 0.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and waterproof plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3J-04ALA
 22 MPC-FBM3J-N9718- EEC-FBM3J-A1724- 03, 05, 08, 10, 15, 20
FBM3J-04ALA
 42 MPC-FBM3J-B9718-
EEC-FBM3J-A1724-
03, 05, 08, 10, 15, 20
