1.1 System Configurations
The following tables show the possible system configurations; in other words, the various
motors and drives available with their corresponding cables.
FM9 Spindle Motors
SPINDLE MOTOR
MODEL
COMPACT SINGLE-DRIVE
MODEL
SPINDLE MOTOR.
400 Vac
FM9-A004-S5C
 -E01 QC-CD-021-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 3.7/5.5 kW,
MTL MEH 30-1024 incremental TTL
encoder, 1024 P/R, plain shaft or with key.
FM9-A004-C5C
 -E01 QC-CD-021-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 3.7/5.5 kW,
SRS50 sinusoidal absolute single-turn
encoder, 1024 P/R, plain shaft or with key.
FM9-A006-S5C
 -E01-  QC-CD-030-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 5.5/7.5 kW,
MTL MEH 30-1024 incremental TTL
encoder, 1024 P/R, plain shaft or with key.
FM9-A006-C5C
 -E01-  QC-CD-030-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 5.5/7.5 kW,
SRS50 sinusoidal absolute single-turn
encoder, 1024 P/R, plain shaft or with key.
FM9-A008-S5C
 -E01-  QC-CD-030-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 7.5/11.0 kW,
MTL MEH 30-1024 incremental TTL
encoder, 1024 P/R, plain shaft or with key.
FM9-A008-C5C
 -E01-  QC-CD-030-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 7.5/11.0 kW,
SRS50 sinusoidal absolute single-turn
encoder, 1024 P/R, plain shaft or with key.
FM9-A011-S5C
 -E01-  QC-CD-040-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 11.0/15.0 kW,
MTL MEH 30-1024 incremental TTL
encoder, 1024 P/R, plain shaft or with key.
FM9-A011-C5C
 -E01-  QC-CD-040-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 11.0/15.0 kW,
SRS50 sinusoidal absolute single-turn
encoder, 1024 P/R, plain shaft or with key.
FM9-A015-S5C
 -E01 QC-CD-055-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 15.0/22.0 kW,
TS5208N500 incremental TTL encoder,
1024 P/R, plain shaft or with key.
FM9-A015-C5C
 -E01 QC-CD-055-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 15.0/22.0 kW,
SRS50 sinusoidal absolute single-turn
encoder, 1024 P/R, plain shaft or with key.
FM9-A008-S5C
 -E02-A QC-CD-030-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 7.5/11.0 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft and with key.
