8|52 - BCS3D EtherCAT Beta EtherCAT Servo 3 Drive series | Ref.2403
Installation Manual
SPINDLE MOTOR
MODEL
COMPACT SINGLE-DRIVE
MODEL
SPINDLE MOTOR.
400 Vac
FM9-A011-S5C
 -E02 QC-CD-040-F  - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 11.0/15.0 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft and with key.
FM9-A006-S5C0-E03 QC-CD-021-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 5.5/7.5 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft.
FM9-A008-S5C0-E03-A QC-CD-030-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 7.5/11.0 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft.
FM9-A011-S5C0-E03 QC-CD-040-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 11.0/15.0 kW,
TS5208N500 incremental TTL encoder,
1024 P/R, plain shaft.
FM9-A015-S5C0-E03-D QC-CD-055-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: 15.0/18.5 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft.
FM9-A006-S1C0-E04
FM9-A006-S1C0-HS4
QC-CD-030-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: (
 ) 5.5/7.5 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft.
FM9-A008-S1C0-E04
FM9-A008-S1C0-HS4
QC-CD-040-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: (
 ) 7.5/11.0 kW,
TS5291N100 incremental TTL encoder,
1024 P/R, plain shaft.
FM9-A011-S1C0-E04
FM9-A011-S1C0-HS4
QC-CD-055-F
 - 
FAGOR FM9 motor, 400 Vac,
PS1/PS6-40%: (
 ) 11.0/15.0 kW,
TS5208N500 incremental TTL encoder,
1024 P/R, plain shaft.
SPINDLE MOTOR
MODEL
MOTOR
POWER CABLE
 LENGTH (m)
FM9-A004-
 5C  -E01 MPC-4x1.5-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A006-
 5C  -E01-  MPC-4x2.5-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A008-
 5C  -E01-  MPC-4x4-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A011-
 5C  -E01 MPC-4x6-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A015-
 5C  -E01 MPC-4x10-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A008-S5C
 -E02-A MPC-4x4-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A011-S5C
 -E02 MPC-4x6-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A006-S5C0-E03 MPC-4x2.5-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A008-S5C0-E03-A MPC-4x4-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A011-S5C0-E03 MPC-4x6-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A015-S5C0-E03-D MPC-4x10-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A006-S1C0-E04/HS4 MPC-4x2.5-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A008-S1C0-E04/HS4 MPC-4x4-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
FM9-A011-S1C0-E04/HS4 MPC-4x6-M 5, 10, 12, 15, 20, 30, 40, 50, 75, 100, 150, 200, 250, 300
