3 Cables
The following cables are required to connect the system:
ECAT-CABLE-- cable is sold separately.
ECAT-CABLE-FLEX- cable is sold separately.
BSC-EC- cable is sold separately.
BSC-EC-0.3 cable is sold separately.
QC-FBC- cable is sold separately.
QC-FBC-FLEX- cable is sold separately.
This cable is not provided by FAGOR.
CABLE REFERENCE DESCRIPTION  LENGTH (m)
ECAT-CABLE-
EtherCAT cable between
CNCelite and PLC I/Os.
1/2/3/5/7
ECAT- CABLE-FLEX-
10/15/20/25/30/35/35/50/60/75/100
CABLE REFERENCE DESCRIPTION  LENGTH (m)
BSC-EC-
EtherCAT cable between PLC I/Os and BCS3D-
 EA-FS02 drive.
05/10/15
BSC-EC-0.3
EtherCAT cable between BCS3D-
 EA-FS02
drive and BCS3D-
 EA-FS02 drive.
300 mm
CABLE ACCESSORIES - LATHES MACHINES CABLE ACCESSORIES - MILLING MACHINES
BSC-EC-0.3 · 300 mm · 2x BSC-EC-0.3 · 300 mm ·
CABLE REFERENCE DESCRIPTION
 LENGTH (m)
QC-FBC-
SERCOS III cable between
CNCelite and QC-CD--F- drive.
1/2/3/5/7
QC-FBC-FLEX- 10/15/20/25/30/35/50/60/75/100
CABLE REFERENCE DESCRIPTION
LENGTH (m)
STANDARD CABLE
Communication USB 2.0 cable between BCS3D-
 EA-
FS02 drive and PC. A male connector to Mini-B male
connector.
-
