1.2 Mains Filters
It is recomended to insert a mains filter at each axis.
Recommended EMC filters
To comply with the limits based on IEC/EN 61800-3 second environment (C2) the drive and
motor must be installed with an EMC/RFI filter.
Recommended filters are:
MANDATORY.
In order to comply with European Directive 2014/35/EU on Low Voltage (LVD) and 2014/30/EU
on ElectroMagnetic Compatibility (EMC), it is mandatory to insert a mains filter in the system.
IMPORTANT NOTE. It is the user's responsibility to install a mains filter for the QC-CD
single compact drive and another filter for the entire BCS3D system, instead of the
recommended one filter per unit. Use the 'MAIN FILTER' filters available from the FAGOR
catalog and select the filter with sufficient rated current to supply the sum of the rated
currents of all the equipment connected to it. See example in ANNEX A1 and MAINS
FILTERS technical data in the ‘man_qc_pds_hard.pdf’ manual.
LINE VOLTAGE POWER RANGE EMC C2. MAINS FILTERS
200 Vac
200 W ... 1.5 kW SCHAFFNER FN 3270H-10-44
2.0 kW SCHAFFNER FN 3270H-20-44
400 Vac
1.0 kW ... 1.5 kW SCHAFFNER FN 3025HP-10-71
2.0 kW ... 3.0 kW SCHAFFNER FN 3025HP-20-71
5.0 kW SCHAFFNER FN 3025HP-30-71
7.5 kW AEROVED DNF51-3PH-3×20A
SERVOMOTOR
REFERENCE
SERVO DRIVE
REFERENCE
LINE
VOLTAGE
MAINS
FILTER
FBM3J-02ALA
 4 BCS3D-02AEA-FS02 single-ph. 200 Vac SCHAFFNER FN 3270H-10-44
FBM3J-04ALA
 4 BCS3D-04AEA-FS02 single-ph. 200 Vac SCHAFFNER FN 3270H-10-44
FBM3J-08ALA
 4 BCS3D-08AEA-FS02 3-ph. 200 Vac SCHAFFNER FN 3270H-10-44
FBM3J-10ALA
 4 BCS3D-10AEA-FS02 3-ph. 200 Vac SCHAFFNER FN 3270H-10-44
FBM3G-09ALA  4 BCS3D-10AEA-FS02 3-ph. 200 Vac SCHAFFNER FN 3270H-10-44
FBM3G-13ALA
 4 BCS3D-15AEA-FS02 3-ph. 200 Vac SCHAFFNER FN 3270H-10-44
FBM3G-18ALA
 4 BCS3D-20AEA-FS02 3-ph. 200 Vac SCHAFFNER FN 3270H-20-44
FBM3G-09DLA  4 BCS3D-10DEA-FS02 3-ph. 400 Vac SCHAFFNER FN 3025HP-10-71
FBM3G-13DLA
 4 BCS3D-15DEA-FS02 3-ph. 400 Vac SCHAFFNER FN 3025HP-10-71
FBM3G-18DLA
 4 BCS3D-20DEA-FS02 3-ph. 400 Vac SCHAFFNER FN 3025HP-20-71
FBM3G-29DLA
 4 BCS3D-30DEA-FS02 3-ph. 400 Vac SCHAFFNER FN 3025HP-20-71
FBM3G-44DLA
 4 BCS3D-50DEA-FS02 3-ph. 400 Vac SCHAFFNER FN 3025HP-30-71
FBM3G-55DLA
 4 BCS3D-75DEA-FS02 3-ph. 400 Vac AEROVED DNF51-3PH-3×20A
FBM3G-75DLA
 4 BCS3D-75DEA-FS02 3-ph. 400 Vac AEROVED DNF51-3PH-3×20A
INFORMATION.
These filters have been tested with cable lengths of 3 m and 20 m.
