3.6 GND-PLATE-QC-CD
Accessory kit including metal clamps for cable diameters up to 14 mm (2 pcs.) and up to 20
mm (1 pcs.), GP-1 and GP-2 grounding plates (2 pcs.) and support brackets (4 pcs.) for
connecting the shield of the ’motor - compact single-drive’ power cable and feedback cables
to the Protective Earth.
Kit parts
Shielded connection clamp
Spring-loaded pressure piece with knurled screw. Used as terminal for screen connection
with grounding plate mounting. Contact resistor < 1 m
.. See mounting details in the figure
SCHEMATIC CONNECTION DIAGRAM.
INFORMATION.
Please note that the GND-PLATE-QC-CD accessory kit is not supplied with the
equipment and is ONLY available upon request.
Order code: 88268031.
NOTE. ALWAYS be sure to order the GND-PLATE-QC-CD accessory kit in a padded
envelope for the Protective Earth connection of both the ’motor - compact single-drive’
power and feedback cables.
MANDATORY. ALWAYS connect the shield of the ’motor - compact single-drive’
power and feedback cables to the GP-1 and GP-2 grounding plates, respectively,
as shown in the figure
SCHEMATIC CONNECTION DIAGRAM.
Parts No. of units
Shielded connection clamp - SK 14 for Øcable up to 14 mm 2
Shielded connection clamp - SK 20 for Øcable up to 20 mm 1
Grounding plate, length: 120 mm 2
Support bracket 4
Technical data
Gap (mm)
17
Screw thread M4
Tightening torque (N·m)
0.8
Permissible cable outside diameter (mm) 3 ... 14
Technical data
Gap (mm)
24
Screw thread M4
Tightening torque (N·m)
0.8
Permissible cable outside diameter (mm)
5 ... 20
